reliable design
hundreds of applications,
thousands of satisfied customers worldwide
all parts interchangeable with original Sauer
all parts produced by top quality European manufacturers
easy maintenance and repair
| Parameter | Dimension | PV 20 | PV 21 | PV 22 | PV 23 | PV 24 | PV 25 | PV 26 | PV 27 |
|---|---|---|---|---|---|---|---|---|---|
| Max. displacement per revolution | cm3 | 33,3 | 51,6 | 69,8 | 89,0 | 118,7 | 165,8 | 227,3 | 333,7 |
| Max. flow | dm3 .min-1 | 119,54 | 159,96 | 196,14 | 230,51 | 278,94 | 348,18 | 429,59 | 557,28 |
| Displacement per rev. of the charge pump | cm3 | 12,3 | 12,3 | 18,03 | 18,03 | 18,8 | 32,8 | 32,8 | 65,5 |
| Max.pressure | MPa | 35 | 35 | 35 | 35 | 35 | 35 | 35 | 35 |
| Nominal pressure | MPa | 21 | 21 | 21 | 21 | 21 | 21 | 21 | 21 |
| Max. pressure of control | MPa | 3,5 | 3,5 | 3,5 | 3,5 | 3,5 | 3,5 | 3,5 | 3,5 |
| Charge pressure | MPa | 0,8-2,0 | 0,8-2,0 | 0,8-2,0 | 0,8-2,0 | 0,8-2,0 | 0,8-2,0 | 0,8-2,0 | 0,8-2,0 |
| Max. case pressure | MPa | 5 V | 5 V | 5 V | 5 V | 5 V | 5 V | 5 V | 5 V |
| Pracovná teplota | -20℃ až +60℃ | -20℃ až +60℃ | -20℃ až +60℃ | -20℃ až +60℃ | -20℃ až +60℃ | -20℃ až +60℃ | -20℃ až +60℃ | -20℃ až +60℃ | -20℃ až +60℃ |
| Životnosť | Vyše 50.000 hodín | Vyše 50.000 hodín | Vyše 50.000 hodín | Vyše 50.000 hodín | Vyše 50.000 hodín | Vyše 50.000 hodín | Vyše 50.000 hodín | Vyše 50.000 hodín | Vyše 50.000 hodín |
| Výška stĺpu | 5 – 12 m | 5 – 12 m | 5 – 12 m | 5 – 12 m | 5 – 12 m | 5 – 12 m | 5 – 12 m | 5 – 12 m | 5 – 12 m |
| Vrchný priemer stĺpu | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
